Phoenix TMI Pisces Cement Compression Testing Machine - 300 kN

PHOENIX TMI PISCES 300 kN CEMENT COMPRESSION TESTING MACHINE

Phoenix TMI Pisces 300 kN is a dedicated cement compression testing machine designed to determine the compressive strength of cement mortar and construction materials. The machine provides a maximum load capacity of 300 kN and integrates an electronic force measurement system with the Phoenix TMI Aquila controller.

Technical Specifications

Maximum Load Capacity:

300 kN

Force Measurement Range:

2-100% FS

Force Accuracy:

±1% (Class 1)

Loading Speed:

0.1 - 5 mm/min

Loading Speed Accuracy:

±5%

Piston Stroke:

80 - 150 mm

Maximum Distance Between Compression Platens:

180 - 250 mm

Distance Between Columns:

190 - 220 mm

Compression Platen Size:

Ø200mm

Force Measurement System:

Pressure sensor

Motor Power:

1 kW

Power Supply:

220V - 50 Hz

Supported Standards:

TCVN / ASTM

Specimen Size:

40 x 40 mm; 40 x 40 x 160 mm

Detailed Description

PHOENIX TMI PISCES 300 kN CEMENT COMPRESSION TESTING MACHINE

Phoenix TMI Pisces 300 kN is a dedicated cement compression testing machine designed to determine the compressive strength of cement mortar specimens and other compatible construction material samples in material testing laboratories.

The machine provides a maximum compression capacity of 300 kN and is suitable for cement and mortar specimens such as 40 × 40 mm cubes and 40 × 40 × 160 mm prism specimens when used with the appropriate fixtures and accessories.

The system is designed for testing laboratories, research centers, cement plants, construction companies, and other organizations that require material quality testing in accordance with domestic and international test standards.

Applications

Phoenix TMI Pisces 300 kN can be used for applications including:

Determination of the compressive strength of cement mortar
Compression testing of 40 × 40 mm specimens
Testing of 40 × 40 × 160 mm mortar prism specimens with suitable accessories
Quality control of cement and construction materials in laboratories
Other compression tests within the machine’s load capacity

Force Measurement System

The machine uses the Phoenix TMI Precision pressure/force measurement system to monitor the applied load throughout the test.

Test data is displayed directly on the Phoenix TMI Aquila controller, allowing the operator to monitor key test parameters during the loading process.

Phoenix TMI Aquila Controller

Phoenix TMI Pisces 300 kN is equipped with the Phoenix TMI Aquila display and control unit, developed for material compression testing systems.

The system allows the operator to:

Monitor load values in real time
View test results directly on the display
Perform testing procedures more conveniently
Expand connectivity and data-processing capabilities
Upgrade the system for computer connection to support test data acquisition, storage, and processing

Robust Mechanical Structure

The machine frame is designed with high rigidity to maintain stability throughout the loading process.

An integrated cement specimen compression fixture is provided to simplify specimen positioning and laboratory testing procedures.

The overall system is designed for straightforward operation and convenient maintenance, calibration, and long-term use.

APPLICATION STANDARDS| COMPLIES WITH STRINGENT STANDARDS

Phoenix TMI Pisces 300 kN is designed to support a wide range of material testing methods in accordance with multiple national and international standards.
